Centrifugal oil filter machine, oil filter centrifuge, small centrifugal oil filter
Centrifugal oil filter – China suppliers, manufacturers
Centrifugal oil filter machine is a highly efficient filtration device used to remove water or impurities that affect the normal consumption of oil. It uses high-speed rotating centrifugal force to separate solid and liquid of different weights. This device has wide application and pairs well with oil presses, making it a necessary tool in many vegetable oil mills.
Product Parameter:
| Model | Capacity | Power | Voltage | Packing size(mm) | Weight(KG) |
| BL50 | 150-200Kg/h | 2.2KW | 380V/50HZ | 750*500*950mm | 120 |
| BL60 | 200-300Kg/h | 4KW | 380V/50HZ | 850*600*950mm | 160 |
| BL70 | 300-400Kg/h | 4KW | 380V/50HZ | 1000*700*950mm | 200 |
Features and advantages of centrifugal oil filter:
1, The intelligent handling Just pour the crude oil pressed by the oil press into the feeding mouth, the intelligent feeding and automatic separation of oil and residues are realized; the labor forth of that is 90% lower than the old traditional oil filter.
2, The intelligent reaction is not chemical reaction without any chemical ingredients, tarnish and smell. There is no oil residue and oily smell which keep the original flavor of the oil. And the oil quality is clean and health.
3, The intelligent separation of oil and residues that the residues content of the filtered oil is below 2%. The effect of it is 50% better than the old oil filer.
4, Intelligent energy saving that filtering a barrel of oil need 4-5 minutes every time, the filtering amount is about 200-250Kg per hours. The daily power consumption is below 10 degree which is 30% less energy using than the old filter.
5, The machine has the features of new design, small volume, less occupation, small and reasonable structures, nice outlook and long life service.
6, High oil output and the centrifugal oil filter don’t use filtering cloth or filtering screen. The oil filter use a piece of filter cloth to absorb about 0.5 kg oil; about 50kg net oil have been consumed per year; residues of the artificial way of removing phosphor has high oil contents(2-3%). The net oil consumption is about hundreds of it per year.
How to use the centrifugal oil filter:
The centrifugal oil filter machine is easy to use. First, turn on the power supply of the centrifuge and add the crude oil. The crude oil flows from the oil hopper through the hollow axle at the upper end of the centrifugal oil filter to the nylon disc at the bottom of the drum. The small disc quickly distributes the crude oil evenly to the inner wall of the drum. At this time, the strong centrifugal force generated by the high-speed rotating drum separates the solid and liquid of different weights. After 2-4 minutes, the power is turned off, and the drum gradually stops rotating. The net oil automatically flows out in just 5-6 minutes, with a filtration capacity of 250-350 kg oil per hour.
Centrifugal Oil Filter – Professional China Suppliers
The centrifugal oil filter is made of high quality stainless steel material, the treated oil has high purity and bright color, and effectively separates the impurities in the oil. Most of the vegetable oil mill’s pressed oil needs to be filtered by the oil filter before it can be eaten, thus ensuring the pure taste of the edible oil. The benefits of using a centrifugal oil filter machine are many. It is a highly efficient and necessary tool for vegetable oil mills. It is easy to use, requires minimal maintenance, and produces high-quality, pure edible oil. Using this device ensures the pure taste of the edible oil, making it a valuable investment for any vegetable oil mill.
